3GMAB50500
Screw Machine Button-HD 1/2-13-THD 127mm-LG 5in-LG Stainless Steel 18-8
Similar Components
3GSAF12100
Screw Self Tapping Flat-HD 12-24-THD 25.4mm-LG 1in-LG Stainless Steel 18-8
3GMKB31050
Screw Machine Button-HD 5/16-18-THD 12.7mm-LG Stainless Steel 18-8
93GMKF08070
Screw Machine Flat-HD M8 X 1.25-THD 70mm-LG Stainless Steel 18-8
3GSAB08050
Screw Self Tapping Button-HD 8-THD 12.7mm-LG Stainless Steel 18-8
93GMKB16050#
Machine Screw, 18-8 Stainless Steel, 5/8 in Body Diameter
3GSKB04031
Screw Self Tapping Button-HD 4-THD 7.92mm-LG Stainless Steel 18-8
About 3GMAB50500
The Bryce Fastener 3GMAB50500 Fasteners datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Screw Machine Button-HD 1/2-13-THD 127mm-LG 5in-LG Stainless Steel 18-8. Key parameters include Body Diameter (Imperial - Decimal) (in): 0.5, Body Diameter (Imperial) (in): 1/2, Body Diameter (Metric) (mm): 12.7, Body Length (Imperial) (in): 5, and Body Length (Metric) (mm): 127. 3GMAB50500 is manufactured by Bryce Fastener as part of their Fasteners product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Bryce Fastener
- Category
- Fasteners
Ask AI Assistant
Ask questions about 3GMAB50500 specifications
Click to ask a quick question:
Parameters
| Body Diameter (Imperial - Decimal) (in) | 0.5 |
| Body Diameter (Imperial) (in) | 1/2 |
| Body Diameter (Metric) (mm) | 12.7 |
| Body Length (Imperial) (in) | 5 |
| Body Length (Metric) (mm) | 127 |
| Cage Code | 3CJH1 |
| ECCN | EAR99 |
| EU RoHS | Yes |
| Head Type | Button |
| HTS Code | 7318158082 |
| Material | Stainless Steel 18-8 |
| Point Type | Die |
| RoHS Versions | 2002/95/EC |
| Schedule B | 7318159000 |
| Thread Length (Imperial - Decimal) (in) | 5 |
| Thread Length (Imperial) (in) | 5 |
| Thread Length (Metric) (mm) | 127 |
| Type | Machine |
