3GMAB31150
Screw Machine Button-HD 5/16-18-THD 38.1mm-LG Stainless Steel 18-8
Similar Components
93GMKB10060
Screw Machine Button-HD M10 X 1.5-THD 60mm-LG Stainless Steel 18-8
93GMKB08040#
Screw Machine Button-HD M8 X 1.25-THD 40mm-LG Stainless Steel 18-8
3GSKB10200#
Screw Self Tapping Button-HD 10-THD 50.8mm-LG 2in-LG Stainless Steel 18-8
93GMKB05016
Screw Machine Button-HD M5 X 0.8-THD 16mm-LG Stainless Steel 18-8
93GMKB06012#
Machine Screw, Stainless Steel 18-8, 6mm Diameter, 12mm Length
93GMKF08080
Screw Machine Flat-HD M8 X 1.25-THD 80mm-LG Stainless Steel 18-8
About 3GMAB31150
The Bryce Fastener 3GMAB31150 Fasteners datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Screw Machine Button-HD 5/16-18-THD 38.1mm-LG Stainless Steel 18-8. Key parameters include Body Diameter (Imperial - Decimal) (in): 0.3125, Body Diameter (Imperial) (in): 5/16, Body Diameter (Metric) (mm): 7.94, Body Length (Imperial - Decimal) (in): 1.5, and Body Length (Metric) (mm): 38.1. 3GMAB31150 is manufactured by Bryce Fastener as part of their Fasteners product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Bryce Fastener
- Category
- Fasteners
Ask AI Assistant
Ask questions about 3GMAB31150 specifications
Click to ask a quick question:
Parameters
| Body Diameter (Imperial - Decimal) (in) | 0.3125 |
| Body Diameter (Imperial) (in) | 5/16 |
| Body Diameter (Metric) (mm) | 7.94 |
| Body Length (Imperial - Decimal) (in) | 1.5 |
| Body Length (Metric) (mm) | 38.1 |
| Cage Code | 3CJH1 |
| ECCN | EAR99 |
| EU RoHS | Yes |
| Head Type | Button |
| HTS Code | 7318158082 |
| Material | Stainless Steel 18-8 |
| Point Type | Die |
| RoHS Versions | 2002/95/EC |
| Schedule B | 7318159000 |
| Thread Length (Imperial - Decimal) (in) | 1.5 |
| Thread Length (Metric) (mm) | 38.1 |
| Type | Machine |
