The Littelfuse 39501600000 Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: Fuse Subminiature Fast Acting 0.16A 125V Radial 8.5 X 8mm Ammo UL. Key parameters include Approvals: UL, Color: Brown, Current Rating: 160mA, DC Cold Resistance: 4.285R, and DC Rated Voltage: 125V. 39501600000 is manufactured by Littelfuse as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.

Specifications

Manufacturer: Littelfuse
Category: Fuses Fuse Holders

Ask AI Assistant

Ask questions about 39501600000 specifications

AI Powered

Click to ask a quick question:

Parameters

Approvals	UL
Color	Brown
Current Rating	160mA
DC Cold Resistance	4.285R
DC Rated Voltage	125V
Flammability Rating	UL94 V-0
Fuse Current	160mA
Height	0.315inch
Lead Free	Lead Free
Lead Length	18.8mm
Length	0.335inch
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Mount	Through Hole
Package/Case	Radial
Package Quantity	1400
Packaging	Tape and Reel
Reach SVHC Compliant	Unknown
RoHS	Compliant
RoHS Compliant	Yes
Series	TE5® 395
Termination	Radial
Voltage Rating (AC)	125V
Width	0.157inch
