03420858HXP
250V 20A Panel Mount Fuse, 1AG, 1-1/4\
Similar Components
04820001ZXPF
481 Alarm Fuse, 125V, 15A, Panel Mount, PC Pin Termination
FLM008
Fuse Midget Slow Blow Acting 8A 250V Holder Cartridge 10.31 X 38.1mm CE/CSA/UL
01020074H
FUSE CLIP CARTRIDGE 250V 15A PCB
39811600000
TE5 398 1.6A 65V Radial Through Hole Fuse
04822001ZXPF
20A 125VDC/125VAC Illuminated Fuse Holder, Panel Mount
01220088H
250V 30A Through Hole Fuse, Copper Body, Lead Free, PC Pin Termination
About 03420858HXP
The Littelfuse 03420858HXP Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 250V 20A Panel Mount Fuse, 1AG, 1-1/4\. Key parameters include Body Material: Thermoplastic, Color: Black, Contact Material: Copper Alloy, Contact Plating: Nickel, and Current Rating: 20A. 03420858HXP is manufactured by Littelfuse as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Littelfuse
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about 03420858HXP specifications
Click to ask a quick question:
Parameters
| Body Material | Thermoplastic |
| Color | Black |
| Contact Material | Copper Alloy |
| Contact Plating | Nickel |
| Current Rating | 20A |
| DC Rated Voltage | 250V |
| Flammability Rating | UL94 V-0 |
| Fuse Size | 3AG, 1-1/4" L x 1/4" Dia (31.8mm x 6.35mm) |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Material | Brass, Tin |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Panel |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Package Quantity | 100 |
| Packaging | Bulk |
| RoHS | Compliant |
| Series | 342 |
| Termination | Quick Connect |
| Voltage | 250V |
| Voltage Rating | 250V |
