03420828H
250V 20A Fuse Holder, Panel Mount, Quick Connect, Illuminated
Similar Components
03452LF7H
250V 10A Panel Mount Fuse, Illuminated, Lead Free, UL94 V-0
37400800430
TR5 374 250V 80mA Through Hole Radial Fuse
03455QS8X
Fuse Holder Panel Mount
38312500000
TR5 383 2.5A 300V Radial Through Hole Fuse
02820002Z
Illuminated Fuse Holder, 5A, 125V, Panel Mount, Radial
20100630001P
63mA Holder Mount Fuse, 250V AC, 70°C, cULus
About 03420828H
The Littelfuse 03420828H Fuses Fuse Holders datasheet provides detailed technical specifications, pinout information, and operating characteristics. This component: 250V 20A Fuse Holder, Panel Mount, Quick Connect, Illuminated. Key parameters include Color: Black, Contact Material: Brass, Contact Plating: Nickel, Current Rating: 20A, and DC Rated Voltage: 250V. 03420828H is manufactured by Littelfuse as part of their Fuses Fuse Holders product line. On this page you can view and download the PDF datasheet, check specifications, and find similar components.
Specifications
- Manufacturer
- Littelfuse
- Category
- Fuses Fuse Holders
Ask AI Assistant
Ask questions about 03420828H specifications
Click to ask a quick question:
Parameters
| Color | Black |
| Contact Material | Brass |
| Contact Plating | Nickel |
| Current Rating | 20A |
| DC Rated Voltage | 250V |
| Depth | 17.53mm |
| Diameter | 17.5mm |
| Fuse Current | 20A |
| Fuse Size | 0.25 Dia x 1.26 L (6.35mm x 32mm) |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Length | 20.23mm |
| Material | Thermoplastic |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Panel |
| Number of Circuits | 1 |
| Number of Poles | 1 |
| Package Quantity | 100 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS | Compliant |
| Series | 342 |
| Termination | Quick Connect |
| Voltage | 250V |
| Voltage Rating | 250V |
| Voltage Rating (AC) | 250V |
